Distributed loads are specified as described in Distributed Loads. Gravity,
centrifugal, rotary acceleration, and Coriolis force loads apply only if the surface
elements have rebar defined or if the elements have a defined density.
*dload
- Load ID (*DLOAD):
BX
-
Body force
-
FL−2
-
Body force in the global X-direction.
- Load ID (*DLOAD):
BY
-
Body force
-
FL−2
-
Body force in the global Y-direction.
- Load ID (*DLOAD):
BZ
-
Body force
-
FL−2
-
Body force in the global Z-direction.
- Load ID (*DLOAD):
BXNU
-
Body force
-
FL−2
-
Nonuniform body force in the global X-direction with magnitude
supplied via user subroutine DLOAD in Abaqus/Standard and VDLOAD in Abaqus/Explicit.
- Load ID (*DLOAD):
BYNU
-
Body force
-
FL−2
-
Nonuniform body force in the global Y-direction with magnitude
supplied via user subroutine DLOAD in Abaqus/Standard and VDLOAD in Abaqus/Explicit.
- Load ID (*DLOAD):
BZNU
-
Body force
-
FL−2
-
Nonuniform body force in the global Z-direction with magnitude
supplied via user subroutine DLOAD in Abaqus/Standard and VDLOAD in Abaqus/Explicit.
- Load ID (*DLOAD):
CENT
(S)
-
Not supported
-
FL−3 (ML−2T−2)
-
Centrifugal load (magnitude is input as
, where
is the mass density per unit area,
is the angular speed).
- Load ID (*DLOAD):
CENTRIF
(S)
-
Rotational body force
-
T−2
-
Centrifugal load (magnitude is input as
, where
is the angular speed).
- Load ID (*DLOAD):
CORIO
(S)
-
Coriolis force
-
FL−3T (ML−2T−1)
-
Coriolis force (magnitude is input as
, where
is the mass density per unit area,
is the angular speed). The load stiffness due to Coriolis loading
is not accounted for in direct steady-state dynamics analysis.
- Load ID (*DLOAD):
GRAV
-
Gravity
-
LT−2
-
Gravity loading in a specified direction (magnitude is input as acceleration).
- Load ID (*DLOAD):
HP
(S)
-
Not supported
-
FL−2
-
Hydrostatic pressure applied to the element reference surface and linear in global
Z. The pressure is positive in the direction of the positive
element normal.
- Load ID (*DLOAD):
P
-
Pressure
-
FL−2
-
Pressure applied to the element reference surface. The pressure is positive in the
direction of the positive element normal.
- Load ID (*DLOAD):
PNU
-
Not supported
-
FL−2
-
Nonuniform pressure applied to the element reference surface with magnitude
supplied via user subroutine DLOAD in Abaqus/Standard and VDLOAD in Abaqus/Explicit. The pressure is positive in the direction of the positive element normal.
- Load ID (*DLOAD):
ROTA
(S)
-
Rotational body force
-
T−2
-
Rotary acceleration load (magnitude is input as
, where
is the rotary acceleration).
- Load ID (*DLOAD):
SBF
(E)
-
Not supported
-
FL−5T2
-
Stagnation body force in global X-, Y-,
and Z-directions.
- Load ID (*DLOAD):
SP
(E)
-
Not supported
-
FL−4T2
-
Stagnation pressure applied to the element reference surface.
- Load ID (*DLOAD):
TRSHR
-
Surface traction
-
FL−2
-
Shear traction on the element reference surface.
- Load ID (*DLOAD):
TRSHRNU
(S)
-
Not supported
-
FL−2
-
Nonuniform shear traction on the element reference surface with magnitude and
direction supplied via user subroutine UTRACLOAD.
- Load ID (*DLOAD):
TRVEC
-
Surface traction
-
FL−2
-
General traction on the element reference surface.
- Load ID (*DLOAD):
TRVECNU
(S)
-
Not supported
-
FL−2
-
Nonuniform general traction on the element reference surface with magnitude and
direction supplied via user subroutine UTRACLOAD.
- Load ID (*DLOAD):
VBF
(E)
-
Not supported
-
FL−4T
-
Viscous body force in global X-, Y-, and
Z-directions.
- Load ID (*DLOAD):
VP
(E)
-
Not supported
-
FL−3T
-
Viscous surface pressure applied to the element reference surface. The pressure is
proportional to the velocity normal to the element face and opposing the motion.
